RFID Temperature-Sensitive Labels, Glossy White Polyester

UHF temperature-sensitive RFID labels for reliable monitoring

These glossy white temperature-sensitive UHF RFID polyester labels are designed for applications that require a combination of temperature detection and digital identification. The label functions as a general-purpose temperature sensor and can be applied to a wide range of non-metallic surfaces. This makes it suitable for situations where temperature deviations affect quality, safety, or process control in professional environments.

By combining temperature indication with UHF RFID technology, this label offers both remote detection and identification. This makes the label suitable for use in logistics, industrial, and technical processes where continuous monitoring is required.

UHF RFID technology with a long read range

The tag operates at UHF frequencies within the 860 to 960 MHz range and complies with EPC Class 1 Gen2v2 and ISO 18000-63. This makes it compatible with standard UHF RFID readers and existing RFID infrastructures. The RF Micron Magnus S3E chip used in this label is designed for temperature-related applications and delivers stable read and detection performance.

The maximum read range is up to nine meters, allowing objects to be read efficiently without physical contact. This supports inventory management, inspections, and automated monitoring processes in a variety of environments.

Temperature Detection for Process Monitoring

The UHF temperature label makes it possible to determine whether an object has been exposed to temperatures outside predetermined limits. This is relevant in processes where temperature control is essential, such as storage, transportation, or production.

The combination of temperature detection and RFID reading makes it possible to digitally record temperature data and link it to individual items or batches. This provides additional insight into process conditions without the need for manual measurements or additional sensors.

Durable B-423 polyester for indoor and outdoor use

The label is made of glossy white B-423 polyester and is suitable for both indoor and outdoor use. It operates reliably within a temperature range of -70 °C to 110 °C and is resistant to UV light and mechanical stress. This ensures the label remains usable for a long time in demanding environments.

The material is halogen-free and UL-approved and CSA-accepted for the white version, which supports use in regulated environments.

Reliable construction and installation

The RFID chip is attached to an aluminum antenna using anisotropic conductive film adhesive. This design ensures stable electrical performance and consistent readability. The antenna is designed for mounting on non-metallic surfaces such as cardboard, wood, plastic, and glass.

Applications in Industry and Logistics

These temperature-sensitive UHF RFID labels are used for temperature indication, general identification, and RFID labeling in industrial, logistics, manufacturing, and technical environments. They support processes where monitoring, traceability, and reliability are key.
